For use in the Formbot Raptor and Raptor 2, T-REX 2, 2 , 3 or other 3D printers with removable stepper drivers. We have tested these thoroughly on the X and Y axis on the Formbot machines with great results!

For the Raptor, you will need at least 2 pieces (up to 4).  For the T-REX, at least 3 (up to 6)

NOTE: Firmware changes are needed!

• Hardware compatible with  and
• Drive capability up to 1.2A (RMS) continuous coil current - 2A Peak
• Step/Dir interface with microstep interpolation (up to 256 microsteps)
• Configuration via CFG pins or UART interface
• Motor supply voltage: 5.5...36V
• Logic supply voltage: 3.3...5V
• Components on the bottom for better heat dissipation
• stealthChop2 - for quiet operation and smooth motion (default setting)
• spreadCycle - highly dynamic motor control chopper (enabled via UART)
• Authentic TMC chip assembled by MKS
• Recommend current

Included:
